I-DT61PW
Advanced IP68/IP69K Washdown Indicator
| Resolution | 75,000 |
| Battery Life | 1600 Hours with Disposable Batteries |
| Outputs | Not Applicable |
| Item Number: | 30575578 |
I-DT61PW
Advanced IP68/IP69K Washdown Indicator
| Resolution | 75,000 |
| Battery Life | 1600 Hours with Disposable Batteries |
| Outputs | Not Applicable |
| Item Number: | 30575580 |
OVERVIEW
|
Applications Weighing, Counting with APW optimization, Percent Weighing, Checkweighing, Checkcounting, Filling, Dynamic Weighing/Display Hold Display 6-digit, 7-segment white LED, 20 mm high digits Operation 100-240 VAC / 50/60 Hz universal power supply, hardwired Communication Easy access communication ports including RS232 and USB Host, second RS23
|
SPECIFICATIONS
| Resolution | 75,000 |
| Battery Life | 1600 Hours with Disposable Batteries |
| Outputs | Not Applicable |
| Second Scale Input | Not Applicable |
| Protection Rating | IP69k; IP68 |
| Communication | Infrared communication kit (available as an accessory) |
| Dimensions | 10.4 in x 8.9 in x 3.3 in (265 mm x 225 mm x 85 mm) (LxHxW) |
| Display | 7-Segment LCD with white backlight, height 45mm + 3 Color Checkweigh LED |
| Legal for Trade | EC Type Approvable; OIML |
| Net Weight | 6 lb (2.7 kg) |
| Power | 6 D (LR20) batteries (included) |
| Tare Range | To capacity by subtraction |
| Units of Measurement | Metric Tons; Gram; Kilogram; Pound; Ounce; Pound:Ounce |
| Working Environment | 14°F – 104°F, 80%RH, non-condensing (-10°C – 40°C, 80%RH, non-condensing) |
ACCESSORIES
|
Item Number 30424409 Description Cable Extension 9m D52 |
|||
|
Item Number 30379716 Description Gland M16 D52 |
|||
|
Item Number 30572910 Description IR Communication Kit |
|||
